XCG953II轮式装载机 Loader XCG953II
一、优越的参数：
娱乐中心1、独有的节能型专利技术，双泵合分流、转向优先，高效节能，动力性更佳，油耗更低。
2、单摇臂，长轴距，通用度极大的零部件。
3、超高的卸高度（3060mm)。
娱乐中心4、超大的额定载重量（3200kg)。
5、优雅的外观，整机高大、协调。
娱乐中心6、结构强度储备充足。
娱乐中心7、优化与仿真技术设计的连杆机构，掘起力大，平稳性好。
8、集中布置的黄油注点，方便维护与保养。
9、合理的桥荷分布，整机稳定性好。
10、优越的整机参数，具有非凡的作业效率。
11、可配有多种选装件以满足不同用户要求。
12、适合挖掘与高卸载工况。
二、参数参数及外形尺寸
| 额定功率 | kw | 162 |
| 外形尺寸 | ||
|---|---|---|
| 全长 | mm | 7380 |
| 全宽 | mm | 2990 |
| 全高 | mm | 3390 |
| ****卸载高度 | mm | 3030 |
| 相应卸载距离 | mm | 1300 |
| 轮胎规格 | PR | 23.5-25-16 |
| 操作质量 | kg | 16300 |
| 铲斗容量 | m3 | 3 |
| 额定载荷 | kg | 5000 |
| 转向角度 | （o） | ±35 |
| 最小转弯半径(铲斗外侧) | mm | 6450 |
| 变速箱 | XG | |
| 变速档位数(前进/后退) | 2/1 | |
| 燃油箱容量 | L | 200 |
| 液压油箱容量 | L | 280 |
| 提升时间 | s | ≤6.8 |
| 工作装置三项和 | s | ≤12.3 |
| 行驶速度 | ||
| 前进 1 档 | km/h | 11.5 |
| 前进 2 档 | km/h | 38 |
| 后退 1 档 | km/h | 16 |
三、可选部件：
动力机：上柴G128G1c、轻质斗、重载斗、加长动臂、侧卸装置、夹木（管、草）装置、高卸载装置、除雪铲装置、液压破碎锤、自动秤重装置、集中润滑装置、暖风、空调（冷暖）、GRAMMER豪华座椅（扶手、头枕、安全带）、AM/FM收音机、PARKER液压软管。
娱乐中心Superior Features
娱乐中心1.Small turning radius is suitable for working in confined areas.
娱乐中心2.Turbocharged engine for excellent performance and high torque reserve.
3.Modified overrun clutch and high-class key bearings for reliable torque converter and transmission.
4.Aluminium-plate, wind-cooled radiator and optimized air flow design provide superior heat dissipation.
娱乐中心5.Full hydraulic, Q-Amp steering unit.
6.Xiagong patent: dual-pump confluence and divided-flow, steering priority, equivalence relief hydraulic system for high efficiency and low oil consumption.
7.Famous fittings and optimized pipelines design，fully leakproof for more reliable and good-looking.
娱乐中心8.New gear-rack control for easy and reliable operation.
9.Modified chassis machining process for more accurate and reliable.
10.Z-bar linkage for high breakout force and exceptional productivity.
娱乐中心11.Quenched integral cutting edge bucket with side teeth for more strength and better wearing resistance.
娱乐中心12.Optional various implements and buckets.
13.Centralized lubrication on the rear chassis, grease fitting with dust cover for easy maintenance and high cleanliness.
14.Waterproof and dustproof electrical components, world-famous maintenance-free batteries, main power supply switch cut off by the negative terminal, for safety and reliability.
15.Dish brake made of ductile iron ensures higher strength and safe brake.
娱乐中心16.A roomy cab with two-colour interior decoration, sound insulation, heat insulation and shock absorption ensures excellent visibility. Air conditioning and heating system are optional.
17.More than twenty kinds of improvements.
Specification
| Rated power | 162kw |
| Overall dimensions | |
|---|---|
| Overall length | 7380mm |
| Overall width | 2990mm |
| Overall height | 3390mm |
| Dumping height | 3030mm |
| Dumping reach | 1300mm |
| Specification of type | 23.5-25-16PR |
| Performance parameters of entire machine | |
| Operating weight | 16300kg |
| Bucket capacity | 3m3 |
| Rated loading capacity | 5000kg |
| Turning angle | ±35o |
| Turning radius | 6450mm |
| Gear box | XG |
| Number of shifts (forward/reverse) | 2/1 |
| Fuel tank capacity | 200L |
| Hydraulic fuel tank capacity | 280L |
| Lifting time | ≤6.8s |
| Total cycling time | ≤12.3s |
| Forward gear I | 11.5km/h |
| Forward gear II | 38km/h |
| Reverse gear I | 16km/h |
娱乐中心Optional equipment
娱乐中心1. AM/FM Radio. 2. Seat belt, arm rest, pillow 3. Grammer Seat. 4. Light-duty bucket, heavy-duty bucket, extended boom 5. Timber grapples, side-dump bucket, high dumping device 6. Heating system, air conditioning system 7. PARKER hydraulic hoses. 8. Engine: Shangchai D9-220 9. Snow-removing bucket, automatic weighing machine, automatic greasing device
