适用于氧化矿，含泥量大，浮选回收率低回液分离困难的矿石，采用全泥氰化炭浆工艺流程。
娱乐中心By adopting the full silt CIP technological process, this equipment is applicable for oxidized ore and the ores with high silt content and low floatation recovery that are difficult to separate.
| 日处理量Capacity | 100t/d | 150t/d | ||
|---|---|---|---|---|
| 产品名称 | 型号规格model | 数量 | 型号规格model | 数量 |
| (台) | (台) | |||
| 颚式破碎机 Jaw crusher | PEV430×650 | 1 | PEV500×900 | 1 |
| 颚式细碎机 Fine Jaw crusher | PEX150×750 | 1 | PEX200×750 | 1 |
| 槽式给矿机 Chute feeder | CG600×600 | 1 | CG600×600 | 1 |
| 高频振网筛 High frequency Vibrating screen | 2MVS1225 | 1 | 2MVS1235 | 1 |
| 节能轴承球磨机 Conservation energy ball mill | MQSZ1530 | 1 | MQSZ1836 | 1 |
| 单螺旋分级机 Spriral classifier | FG-12 | 1 | FG-15 | 1 |
| 浓密机 Thickener | NZ-9 | 1 | NZ-12 | 1 |
| 提升搅拌槽 Lifting agitation tank | XBT1500 | 1 | XBT-2000 | 1 |
| 双叶轮浸出槽 Double impeller leaching and agitating tank | SJ3035 | 1 | SJ3540 | 1 |
| 双叶轮吸附槽 Double impeller aolsorber | XF3035 | 6 | XF3540 | 6 |
| 直线振动筛 Linear vibrating screen | ZS0415 | 2 | ZS0612 | 2 |
| 空气压缩机 Air pressure machine | LEK-C | 1 | LEK-C | 1 |
| 解析电解 Disorption electrowinning set | 430kg/批 | 1 | 430kg/批 | 1 |
| 胶泵 Sand pump | 2PNJ | 6 | 3PNJ | 6 |
| 金泥洗槽 Acid wash tank | SC1115 | 1 | SC1115 | 1 |
| 皮带输送机 Conveyor | DTⅡB500×20 | 3 | DTⅡB500×20 | 3 |
| 日处理量Capacity | 200t/d | 300t/d | ||
|---|---|---|---|---|
| 产品名称 | 型号规格model | 数量 | 型号规格model | 数量 |
| (台) | (台) | |||
| 颚式破碎机 Jaw crusher | PEV600×900 | 1 | PEV600×900 | 1 |
| 颚式细碎机 Fine Jaw crusher | PEX200×1000 | 1 | PEX200×1000 | 1 |
| 槽式给矿机 Chute feeder | CG980×1240 | 1 | CG980×1240 | 1 |
| 高频振网筛 High frequency Vibrating screen | 2MVS2035 | 1 | 2MVS2035 | 1 |
| 节能轴承球磨机 Conservation energy ball mill | MQSZ2136 | 1 | MQSZ2136 | 1 |
| 单螺旋分级机 Spriral classifier | FG-20 | 1 | FG-20 | 1 |
| 浓密机 Thickener | NZ-15 | 1 | NZ-15 | 1 |
| 提升搅拌槽 Lifting agitation tank | XBT2500 | 1 | XBT2500 | 1 |
| 双叶轮浸出槽 Double impeller leaching and agitating tank | SJ4045 | 1 | SJ4045 | 1 |
| 双叶轮吸附槽 Double impeller aolsorber | XF4045 | 6 | XF4045 | 6 |
| 直线振动筛 Linear vibrating screen | ZS0718 | 2 | ZS0718 | 2 |
| 空气压缩机 Air pressure machine | LEK-C | 1 | LEK-C | 1 |
| 解析电解 Disorption electrowinning set | 800kg/批 | 1 | 800kg/批 | 1 |
| 胶泵 Sand pump | 4PNJ | 6 | 4PNJ | 6 |
| 金泥洗槽 Acid wash tank | SC1316 | 1 | SC1316 | 1 |
| 皮带输送机 Conveyor | DTⅡB650×20 | 3 | DTⅡB650×20 | 3 |
