国家行业标准JB/T9041
娱乐中心高效节能吸附槽集浸出和炭吸附工序为一体，形式上与氰化槽相似。吸附槽是保证料浆混合良好，既要使活性炭均匀地悬浮在矿浆中、又要使活性炭磨损小、吸附率达99%以上，工作时槽内矿浆产生轴向和径向流动，通过中空轴充气、叶轮搅拌促使气泡细化，达到物料及活性炭均匀悬浮，吸附饱和的载金炭通过空气提升泵排出槽外，进入下一个流程。
High-efficiency energy saving absorption tank integrates leaching with carbon absorption process and is formally similar to cyanidation vat. . The absorption tank is designed to ensure the proper mixing of feed pulp, namely to enable active carbon to suspend in ore pulp uniformly while minimizing the abrasion of active carbon and reaching an absorption rate of higher than 99%. During the operation, the ore pulp inside the vat flows in an axial and radial direction. The bubble is thinned through inflation by sleeve shaft and mixing by impeller so as to realize the uniform suspension of material and active carbon. The saturated gold carrier carbon is discharged from the vat through air lifting pump and gets into the next procedure.
| 型号规格Model | 槽体尺寸Size of tank | 有效容积Volume | 叶轮转速Impeller revolution | 矿浆浓度 | 功率Power | 质量Weight |
| m | m3 | r/min | （%） | kw | t | |
| XF2.5×2.5 | Φ2.5×2.5 | 10.8 | 57.6 | ＜45 | 2.2 | 3.3 |
| XF2.5×2.8 | Φ2.5×2.8 | 12.6 | 57.7 | ＜45 | 3.0 | 3.67 |
| XF2.5×3 | Φ2.5×3 | 13 | 57.6 | ＜45 | 2.2 | 3.9 |
| XF2.5×3.15 | Φ2.5×3.15 | 13.5 | 57.6 | ＜45 | 2.2 | 4.2 |
| XF3×3 | Φ3×3 | 23 | 50 | ＜45 | 2.2 | 4.9 |
| XF3×3.35 | Φ3×3.35 | 22.3 | 50.5 | ＜45 | 4.0 | 5.29 |
| XF3×3.5 | Φ3×3.5 | 22.97 | 50 | ＜45 | 2.2 | 5.6 |
| XF3.15×3.55 | Φ3.15×3.55 | 29 | 50 | ＜45 | 2.2 | 5.9 |
| XF3.5×3.5 | Φ3.5×3.5 | 29 | 50 | ＜45 | 5.5 | 6.2 |
| XF3.5×4 | Φ3.5×4 | 35.6 | 41.14 | ＜45 | 4 | 6.65 |
| XF4×4.5 | Φ4×4.5 | 52.78 | 33.5 | ＜45 | 4 | 8.29 |
| XF4.5×5 | Φ4.5×5 | 74.75 | 33.5 | ＜45 | 5.5 | 10.8 |
| XF5×5.5 | Φ5×5.5 | 102 | 30.64 | ＜45 | 5.5 | 11.6 |
| XF5.15×5.65 | Φ5.15×5.65 | 118 | 28 | ＜45 | 3.7 | 11.9 |
| XF5.5×6 | Φ5.5×6 | 135 | 24.4 | ＜45 | 7.5 | 14.29 |
| XF6×6.5 | Φ6×6.5 | 170 | 23 | ＜45 | 18.5 | 18 |
| XF6.5×7 | Φ6.5×7 | 215 | 23 | ＜45 | 18.5 | 21 |
| XF7×7.5 | Φ7×7.5 | 269 | 21 | ＜45 | 22 | 29.03 |
| XF7.5×8 | Φ7.5×8 | 331 | 21 | ＜45 | 22 | 32.8 |
| XF8×8.5 | Φ8×8.5 | 402 | 17 | ＜45 | 22 | 42.47 |
| XF8.5×9 | Φ8.5×9 | 480 | 17 | ＜45 | 22 | 46.62 |
| XF9×9.5 | Φ9×9.5 | 572 | 17 | ＜45 | 30 | 53 |
| XF9.5×10 | Φ9.5×10 | 673 | 14 | ＜45 | 30 | 58 |
| XF10×10.5 | Φ10×10.5 | 785 | 14 | ＜45 | 30 | 64 |
| XF11×12 | Φ11×12 | 1140 | 13 | ＜45 | 55 | 73 |
| XF12×13 | Φ12×13 | 1470 | 13 | ＜45 | 75 | 86 |
